Metal marking and precision cutting work today demands speed, clarity, and long-term durability, and that’s exactly where our Fiber Laser Machines come into the picture. We design, manufacture, and supply these machines from Ahmedabad, Gujarat, focusing on real industrial needs where accuracy can’t be compromised and production has to stay smooth every single day.
These machines are widely used in industries where metal parts need permanent marking or clean cutting without damaging the surface. From stainless steel kitchenware, automotive components, and electrical parts to jewellery items and fabrication work, the output stays sharp and readable even after long use. The marking doesn’t fade, and the cutting edges remain clean, which helps products look more professional and reliable.
We don’t keep things limited to just one setup. Our range includes Fiber Marking Machines (20W, 30W, 50W) for precise engraving work, Jewellery Laser Cutting & Engraving Machines for fine detailing, and Fiber Welding Machines for strong and clean metal joining. We also support specialized applications like fabric cutting solutions where speed and accuracy both matter.
What makes these machines practical is the way they simplify production. No physical contact with the material means no tool wear and very low maintenance. Once a design is loaded, the machine follows it with consistent beam accuracy, giving repeatable results even in bulk production. That saves time, reduces errors, and helps businesses complete more work in less time.
We understand that every workshop works differently, so we help customers choose the right machine based on their workload, material type, and production goals. Along with supply, we also provide installation support and technical guidance so the setup runs smoothly from day one.
From our facility in Ahmedabad, Gujarat, we supply Fiber Laser Machines across Gujarat and all over India. If someone is looking to upgrade their production with faster marking, sharper output, and long-term reliability, this range is built to handle real industrial work without complications.
| SPECIFICATION | MODEL |
|---|---|
| INFITEK_FFIBER LASER MACHINE | |
| LASER WAVELENGTH | 1064NM |
| MARKING AREA | 110MMX110MM 150MMX150MM 200MMX200MM |
| LASER POWER | 20W,30W,50W |
| LASER DEVICE | MAX |
| MARKING DEPTH | 0.05 ~ 0.5MM |
| MIN.LINE WIDTH | 0.01MM (0.0004”) |
| M2/ BEAM QUALITYM2 | <1.2 |
| MIN. LETTER | 0.2MM (0.008”) |
| POWER SUPLLY | 220V / 50Hz / 1KVA |
| MINIMUM LATTER SIZE | 1.0 mm (ENGLISH LETTER) |
| POWER ADJUSTMENT | 1 TO 100 % |
| MARKING LINE SPEED | 7000 MM/S |
| COOLING METHOD | AIR COOLING |
| SUPPORTED MATERIAL | Aluminum, MS, BRASS, SS |
| LEAD TIME | 7-10 DAYS |
| WARRANTY | ONE YEAR |
20W ENGRAVING DEPTH CAPABILITY
| Depth Depends on material, spped, frequency & number of passes | |
| MATEERIAL | APPROX DEPTH |
| STAINLESS STEEL | 0.02Mm-0.15mm |
| BRASS / COPPER | 0.02mm-0.15mm |
| ALUMINIUM | 0.03-mm-0.20mm |
| MILD STEEL | 0.03-mm-0.20mm |
| Note : For Deeper engraving, slow speed high power & multiple passes are recommended | |
30W ENGRAVING DEPTH CAPABILITY
| Depth Depends on material, spped, frequency & number of passes | |
| MATEERIAL | APPROX DEPTH |
| STAINLESS STEEL | 0.05Mm-0.30mm |
| BRASS / COPPER | 0.05mm-0.30mm |
| ALUMINIUM | 0.10-mm-0.50mm |
| MILD STEEL | 0.10-mm-0.50mm |
| Note : For Deeper engraving, slow speed high power & multiple passes are recommended | |
50W ENGRAVING DEPTH CAPABILITY
| Depth Depends on material, spped, frequency & number of passes | |
| MATEERIAL | APPROX DEPTH |
| STAINLESS STEEL | 0.1Mm-0.5mm |
| BRASS / COPPER | 0.1mm-0.5mm |
| ALUMINIUM | 0.2-mm-0.8mm+ |
| MILD STEEL | 0.2-mm-0.8mm+ |
| Note : For Deeper engraving, slow speed high power & multiple passes are recommended | |
